Technical Details

• Package / Case TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 175°C (TJ)
• Technology MOSFET (Metal Oxide)
• FET Type N-Channel
• Current - Continuous Drain (Id) @ 25°C 15.4A (Ta), 134A (Tc)
• Rds On (Max) @ Id, Vgs 6.3mOhm @ 100A, 15V
• Power Dissipation (Max) 3.8W (Ta), 300W (Tc)
• Vgs(th) (Max) @ Id 4.5V @ 258µA
• Supplier Device Package PG-TO263-3-2
• Drive Voltage (Max Rds On, Min Rds On) 10V, 15V
• Vgs (Max) ±20V
• Drain to Source Voltage (Vdss) 200 V
• Gate Charge (Qg) (Max) @ Vgs 110 nC @ 10 V
• Input Capacitance (Ciss) (Max) @ Vds 7400 pF @ 100 V
